Description
| Engine (loanword) | Zongshen CB300 natural air-cooled, four-stroke, electric starter | ||
| Displacement | 2790C | ||
| Red Diameter* | Stroke: 75X61 .4 | ||
| Maximum power | 16KW Maximum Horsepower 23hp | ||
| Maximum torque | 21 N;m | ||
| Valve train | Single overhead cam 2-valve | ||
| Fuel supply | PE30 Competition Carburetor | ||
| Ignition type | CDI | ||
| Fuel Economy | ≤354g/kw-h | ||
| Transmission | 5-speed International | ||
| Final drive | #520 Chain;13T/49T | ||
| Frame | Cradle type high strength steel tube | ||
| Rear flat fork | Force shape high strength plate gold 18 inch | ||
| Handlebars | High-strength steel tube Reducing center 28.5mm | ||
| Steering | Forged high strength aluminum alloy full | ||
| Front Shock Absorber | MOJ0 53/58.5-880mm with fixed damping | ||
| Rear Shock Absorber | MOJ0 480mm external airbags, adjustable damping in both directions | ||
| Front Brake | 260mm discs, two-piston calipers | ||
| Rear Brake | 240mm disc, single piston caliper | ||
| Rear Wheel Diagram | Forged Aluminum Full Trail Core Aluminum Figure 2.15-18 | ||
| Front Tires | MOJO deep gear 80/100-21 | ||
| Rear Tires | MOJ0 deep gear 100/90-18 | ||
| wheelbases | 1440mm | ||
| Seat height | 920mm | ||
| Ground Clearance | 280mm | ||
| Vehicle Dimensions | LxWxH:2120x820x1220 | ||
| Fuel Tank Capacity | 6.5L | ||
| Net weight | 120S1kg | ||
| Maximum Load | 110kg | ||
| Packing Dimension | 1860X580X1070mm | ||
| Packing weight | 141kg | ||
Specifications
| Engine (loanword) | Zongshen CB300 natural air-cooled, four-stroke, electric starter | ||
| Displacement | 2790C | ||
| Red Diameter* | Stroke: 75X61 .4 | ||
| Maximum power | 16KW Maximum Horsepower 23hp | ||
| Maximum torque | 21 N;m | ||
| Valve train | Single overhead cam 2-valve | ||
| Fuel supply | PE30 Competition Carburetor | ||
| Ignition type | CDI | ||
| Fuel Economy | ≤354g/kw-h | ||
| Transmission | 5-speed International | ||
| Final drive | #520 Chain;13T/49T | ||
| Frame | Cradle type high strength steel tube | ||
| Rear flat fork | Force shape high strength plate gold 18 inch | ||
| Handlebars | High-strength steel tube Reducing center 28.5mm | ||
| Steering | Forged high strength aluminum alloy full | ||
| Front Shock Absorber | MOJ0 53/58.5-880mm with fixed damping | ||
| Rear Shock Absorber | MOJ0 480mm external airbags, adjustable damping in both directions | ||
| Front Brake | 260mm discs, two-piston calipers | ||
| Rear Brake | 240mm disc, single piston caliper | ||
| Rear Wheel Diagram | Forged Aluminum Full Trail Core Aluminum Figure 2.15-18 | ||
| Front Tires | MOJO deep gear 80/100-21 | ||
| Rear Tires | MOJ0 deep gear 100/90-18 | ||
| wheelbases | 1440mm | ||
| Seat height | 920mm | ||
| Ground Clearance | 280mm | ||
| Vehicle Dimensions | LxWxH:2120x820x1220 | ||
| Fuel Tank Capacity | 6.5L | ||
| Net weight | 120S1kg | ||
| Maximum Load | 110kg | ||
| Packing Dimension | 1860X580X1070mm | ||
| Packing weight | 141kg | ||
Features
1. Strong body
2. Mountain tires, wider than ordinary tires
3. Spring hydraulic shock absorbers
4. New front butterfly integrated bumper, beautiful and strong
Detailed Pictures

Video
Applications
1. Home use
2. Commercial use
3.Cargo use
Certificate

Our Factory
Hangzhou LONGWIN Transportation Limit was founded in 1999. In recent years, it has transformed and upgraded from the traditional manufacturing industry to the trinity of “industry and finance network”, and strives to build a world-leading industrial interconnection ecological platform.
Industry is the solid foundation for LONGWIN to enter the industrial Internet. LONGWIN is famous for its core technology of engines. Its products include motorcycle engines, special vehicle engines, general engine engines, boat engines, and aero engines. Power terminal products include motorcycles, bicycles, tricycles, trolleys, electric vehicles, and yachts. LONGWIN has been deeply involved in the manufacturing business, and has grown into an integration expert of power systems and an industry leader in sophisticated manufacturing.
After more than ten years of development, the technology center has made great breakthroughs in independent innovation, and currently ranks among the best in China’s industry in terms of software and hardware investment and R&D strength. The development idea of the technology center is to quickly realize the commercialization of R&D results, and then use the benefits obtained from the R&D results to promote the further development of the technology center, establish a virtuous cycle mechanism for R&D work, and form a new product development of “production generation, R&D generation, and reserve generation” system. According to the development concept of “three-in-one” design, trial production and testing, the Group Technology Center consists of three resource centers: design center, engineering center and testing center.
The three centers are respectively engaged in product design and design verification; product trial production, process tooling design and verification; product performance testing and verification. There are 47 professional sections with a complete range of disciplines. There are 868 R&D personnel in the Group Technology Center, more than 96% of whom have a bachelor’s degree or above, including 360 senior talents such as masters, doctors, professors, and academicians, and 642 with intermediate and senior titles.
The LONGWIN locomotive manufacturing system uses the internationally advanced AGV flexible assembly line, adopts the logistics support of “intelligent production” and “JIT production”, and has a unique group assembly function and 100% on-line inspection capability of critical components. The company currently has 27 assembly lines and inspection lines for all types of vehicles, with an annual production capacity of 20 million vehicles of various types.
The company has production workshops for general assembly, stamping and welding, injection molding, painting, wire harnesses, seat cushions, etc. There are more than 200 vehicle parts manufacturers in the world providing supporting services for LONGWIN. Under the guidance of lean management and excellent manufacturing, LONGWIN can Deliver products to users all over the world on time with quality and quantity guaranteed.
FAQ
A1: Yes, we accept sample order to test and check quality.
Q2: Do you have MOQ limit?
A2: Yes, we have MOQ limit for mass production, but it depends on model. Please contact us for details.
Q3: How about the lead time?
A3: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.
Q4: How about shipping and delivery time?
A4: Generally, Item will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-7 business days.. Airline and
sea shipping also available.
Packing & Delivery


Why Choose Us!



Production line
